Enzyme-Based Diesel Desulfurization Process Offers Energy, CO 2 Advantages

Larry Linguist,
Michael Pacheco
Energy BioSystems Corp.
Houston

Refiners faced with the dilemma of reducing the sulfur content of diesel fuel while also lowering carbon dioxide emissions may benefit from biodesulfurization (BDS), a proprietary process that uses enzymes to remove sulfur from petroleum.

Biodesulfurization is expected to provide refineries a cost-effective method of meeting the new lower-sulfur standards while providing lower energy consumption and, thus, lower CO₂. Recent studies show that energy requirements and CO₂ generation will be significantly lower if BDS is used instead of hydrodesulfurization (HDS) to remove sulfur.

The difference is most dramatic at very low desulfurization levels.

Double challenge

In 1990 the U.S. ushered in a new era in the petroleum refining industry with the enactment of regulations mandating a significant increase in the quality of on-road diesel fuel by 1993. Since that time, environmental-driven trends have tightened specifications on distillate fuels across much of the international petroleum marketplace, and these trends are continuing.

As the U.S. Environmental Protection Agency (EPA) concentrates on diesel fuel as part of its Tier 2 vehicle emissions proposed regulation, there is widespread belief that the most appropriate fuel sulfur target will be 30-50 ppm (0.03-0.05 wt %). Severe hydrotreating required to attain these low-sulfur levels will result in substantial increases in capital, energy, and maintenance costs.

Frank Gerry, manager-fuels development for British Petroleum, commented at last fall's Society of Automotive Engineers (SAE) Fuels & Lubes meeting that the potential cost to U.S. refiners of investing in low-sulfur diesel could reach $30 billion.

Even without the extra energy required for deep desulfurization, petroleum refining is one of the most energy-intensive industries in the U.S., accounting for approximately 7% of the total energy consumed in the U.S. in 1994.

While refiners are being told to lower sulfur levels of the fuels they produce, they are also being told to lower their CO₂ emissions as part of a worldwide move to reduce greenhouse gases.

At the United Nations Framework Convention for Climate Change conferences in Kyoto, Japan, in 1997 and Buenos Aires, Argentina, in 1998, the world's industrialized nations agreed to an overall cut by 2012 of 5.2% in emissions of six gases linked to purported global warming, most notably CO₂. This places a further strain on refineries, which are a major source of CO₂ emissions in the industrial sector.

Bernard Damin of Elf Aquitaine, who also spoke at the SAE Fuels & Lubes fall 1998 meeting, said that refinery CO₂ emissions will increase as refiners further desulfurize diesel.

HDS and BDS

Hydrotreating is the conventional technology for removing sulfur from diesel fuel.

During HDS, petroleum fractions are subjected to high temperature and pressure in the presence of an inorganic catalyst and hydrogen. Organic sulfur molecules are converted to hydrogen sulfide, which is further processed to yield elemental sulfur. HDS becomes increasingly expensive and less efficient in handling sulfur removal as lower sulfur levels are reached.

BDS is a proprietary process based on naturally occurring aerobic bacteria that can remove organically bound sulfur in sulfur heterocycles of petroleum with minimal degradation of the fuel value of the hydrocarbon matrix. Enzymes in the bacteria selectively oxidize the sulfur, then cleave carbon-sulfur bonds. BDS will operate at ambient temperatures and atmospheric pressure and thus will require substantially less energy than conventional HDS methods to achieve sulfur levels below those required by current regulatory standards.

BDS generates a fraction of the CO₂ that is generated in association with HDS, and it does not require hydrogen. Additionally, BDS can effectively remove some key sulfur-containing compounds that are among the most difficult for HDS to treat. BDS can be used instead of, or complementary with, HDS.

Comparison studies

Comparison studies were recently conducted for the energy consumed and the CO ₂ generated for BDS and HDS processes.

Two cases were considered: desulfurization of diesel from 0.2% to 0.005% sulfur, which represents a refinery without a hydrotreater (i.e., BDS replaces HDS); and desulfurization from 0.05% to 0.005%, which represents use of BDS downstream of a hydrotreater. The comparison is summarized in Table 1 [9,935 bytes].

The energy consumed was calculated as the sum of all energy in the form of electricity used for pumps, compressors, and other equipment; fuel used in direct-fired heaters; fuel converted to biological energy for BDS; and the equivalent energy of methane consumed in hydrogen production for HDS. Conversion of energy from methane combustion to other utilities was assumed to be 100% efficient.

The CO2 generation was calculated as the sum of CO₂ from methane combustion for energy production, hydrogen generation for HDS, and biological activity for BDS. CO₂ generated from methane combustion for energy was assumed to be 100% efficient.

Fig. 1 [57,188 bytes] and Fig 2 [57,188 bytes] illustrate the difference in CO₂ emissions and energy requirements for HDS and BDS. The energy and CO2for the HDS unit are dominated by the energy and CO₂ associated with the hydrogen plant and, to a lesser extent, the heating fuel required to heat the diesel up to HDS temperature.

HDS calculations

Fig. 3 [39,589 bytes] illustrates the boundaries of the energy and CO ₂ calculations for HDS.

It was assumed that a hydrogen plant would be needed to produce the hydrogen necessary to run the HDS reaction. Hydrogen would be produced from methane through the steam reforming and chemical shift reactions, which are as follows:

Reforming reaction: CH₄ + H₂O <-> CO + 3H₂

Chemical shift reaction: CO + H₂O <-> CO₂ + H₂

Hydrogen requirements assumed for the two cases were different. A value of 680 scf/bbl was used for desulfurization of diesel from 0.2% to 0.005%, and 430 scf/bbl was used for desulfurization from 0.5% to 0.005%.

These values were determined from data presented by Mario Baldassari, technology manager, hydroprocessing, ABB Lummus Global Inc., and others at the AIChE 1997 Spring National Meeting. The methane required for hydrogen generation was reported as 251 BTU/scf of hydrogen, as reported in the 1994 third edition of Petroleum Refining Technology and Economics.

Steam, power, and heating fuel requirements for hydrotreaters were also reported in the 1994 third edition of Petroleum Refining Technology and Economics. For the second case, no heating fuel was assumed, as the refinery would most likely expand an existing hydrotreater's capabilities with no additional heat needed.

Energy used in operation of a cooling tower to support HDS was assumed to be negligible in this calculation.

CO₂ from hydrogen production was calculated under the assumption that the steam reforming and chemical shift reactions were carried to completion, and the balance of the methane consumed was for energy in the hydrogen plant. CO₂ generation from methane combustion for other utilities was also calculated.

BDS calculations

Fig. 4 [29,734 bytes] illustrates the boundaries of the energy and CO ₂ calculations for BDS.

As with the HDS unit, methane was assumed for production of energy and steam for the BDS unit. An additional fuel, identified as "carbon source," is provided to the unit as fuel to drive the biochemical reactions.

Utility requirements for a refinery-scale BDS unit were calculated through use of a process simulation created with SuperPro Designer, a software package developed for the biotech industry by Intelligen Inc. Utilities reported were electrical energy for mixers, compressors, and pumps; and chilled water. Chilled water was converted to energy under the assumption of a 15° C. temperature difference in the chilled water through the BDS unit.

CO₂ produced biologically was calculated on the basis of experimental observations of BDS reactors in operation and projected operating parameters for a refinery-scale BDS unit. CO2 generation from other utilities was determined in the same manner as the HDS calculations.

Current work

As the studies presented here illustrate, the CO ₂ generation and energy requirements for the BDS process are substantially lower than the HDS process.

Based on results such as these, Energy BioSystems Corp. is aggressively pursuing methods to further improve the efficiency and reduce the cost of BDS processes. Additionally, the company is developing business alliances for hydroxy phenyl benzene sulfinate (HPBS), a product of the desulfurization process that promises to be a lower-cost and potentially biodegradable building block for the manufacture of detergents.

Work is currently under way to install a 5,000 b/d BDS unit for Petro Star Inc.'s Valdez, Alas., refinery. The unit represents the first commercial license of this BDS technology. Petro Star is a wholly owned subsidiary of Arctic Slope Regional Corp. The Valdez refinery is a major supplier of military jet fuel, marine diesel, and other middle distillate products.

In addition to the Petro Star unit, Total Raffinage Distribution SA has announced its intention to build and operate a BDS pilot plant in one of its European industrial facilities.

Bibliography

• Gary, James H.; Handwerk, Glenn E.; "Petroleum Refining Technology and Economics"; Third Edition; Marcel Dekker Inc.; 1994.
• Pacheco, Michael A., "Status of Biocatalytic Desulfurization of Diesel Fuel," paper presented at Worldwide Catalyst Industry Conference CatCon '98, June 3-5, 1998, Houston.
• Halbert, Thomas; Anderson, George; Markley, Gerald; Gupta, Ramesh; Feinberg, Arnie; Darnell, Charles; "Meeting the Challenge of Deep Diesel Desulfurization"; paper presented at the 15th World Petroleum Congress; Beijing; October 1997.
• Baldassari, Mario C.; Hamilton, Gary L.; Dave, Dilip; "Optimized Hydrogen Utilization Through Integrated Cocurrent/Countercurrent Reactor System Design and Catalysis"; Paper 126e presented at AIChE 1997 Spring National Meeting; March 9-13, 1997; Houston.
• "Methane and Carbon Dioxide Emission Estimates from U.S. Petroleum Sources; Health and Environmental Sciences Department Publication Number 4645, American Petroleum Institute, January 1997.
• Petrick, Michael; Pellegrino, Joan; "An Assessment of Carbon Reduction Technology Opportunities in the Petroleum Refining Industry"; paper presented at 4th International Conference on Greenhouse Gas Control Technologies; August 1998; Interlaken, Switzerland.
• Monthly Energy Review, DOE/EIA-0035, April 1998.
• "Kyoto Conference Yields Treaty U.S. Likely to Reject," OGJ, Dec. 15, 1997, pp. 17-21.
• "U.S. Signs Kyoto Global Warming Treaty," OGJ, Nov. 23, 1998, p. 33.
• "Refiners, Engine Makers, Fuel Additives Suppliers, Regulators All Struggling to Define Path to 'Cleaner' Diesel Future," Hart's Diesel Fuel News, Dec. 7, 1998.
• Gaines, L. L., Wolsky, A.M., "Energy and Material Flows in Petroleum Refining," ANL/CNSV-10, Argonne National Laboratory, February 1981.
• Shahani, G.H., Gardoz, L.J., Murphy, K.J., Baade, W.F., "Hydrogen and Utility Supply Optimization," Hydrocarbon Processing, Septemberer 1998, pp. 143-150.
